Dante Network Amplifier

أنظمة الصوت / نظام الصوت الشبكي Dante

Dante Network Amplifier

الكود: EC-1120   Dante HA-2120   Dante / HA-1250   Dante HA-2250   Dante / HA-1500   Dante HA-2500   Dante

Features Receives input directly through Dante audio network Expansive Dante network functionality for flexible system expansion Seamless Dante-to-amp and amp-to-Dante audio conversion Professional-grade SNR and THD+N performance Ultra-low inrush current – no sequenced power required Dante-enabled: Transmits high-quality, low-latency digital audio over standard Ethernet 120Watts ~ 480Watts output Advanced protection system includes current limiting, over current and thermal protections Desktop type with rack mount bracket Two bands tone controls Low distortion and low noise level Compact in Size and easy to install Ideal for commercial, educational, transportation, and industrial applications requiring networked audio solutions

استفسار واتساب طلب عرض سعر تحميل الكتالوج

المواصفات الفنية

Model
EC-1120   Dante HA-2120   Dante / HA-1250   Dante HA-2250   Dante / HA-1500   Dante HA-2500   Dante
Rated Power at 8ohm
2x60W/4x60W / 2x120W/4x120W / 2x240W/4x240W
Bridged Power at 100V
120W/2x120W / 240W/2x240W / 480W/2x480W
Power Consumption
195W/360W / 325W/635W / 588W/1120W
Network Communication Protocol
Dante
Network Interface
10/100Base-TX, RJ45
Input sensitivity / Impedance
-0dBu/10kohm Balanced
Power Supply Voltage
AC 100-120V, 50/60Hz or AC220-240V, 50/60Hz
Speaker Output
100V / 8Ω
Frequency Response
80Hz~17KHz ( +1dB /-3dB )
S/N Ratio
>80dB (with A-Weight)
T.H.D
<1% (at rated power, 1kHz)
Working Humidity
90%
Output Channel
1 or 2 channel
Tone Controls
Bass:100Hz(±10dB), Treble:10KHz(±10dB)
Working Temperature
0℃~+40℃
Product Dimension (WxHxD)
215*44*330 mm/215*44*380 mm (Half-Rack)
Net Weight
3.3kg/3.6kg

الاستخدامات

Receives input directly through Dante audio network
Expansive Dante network functionality for flexible system expansion
Seamless Dante-to-amp and amp-to-Dante audio conversion
Professional-grade SNR and THD+N performance
Ultra-low inrush current – no sequenced power required
Dante-enabled: Transmits high-quality, low-latency digital audio over standard Ethernet
120Watts ~ 480Watts output
Advanced protection system includes current limiting, over current and thermal protections
Desktop type with rack mount bracket
Two bands tone controls
Low distortion and low noise level
Compact in Size and easy to install
Ideal for commercial, educational, transportation, and industrial applications requiring networked audio solutions
