VoIP Audio Management Server for Network PA & BGM Systems

أنظمة الصوت / نظام الصوت الشبكي IP

VoIP Audio Management Server for Network PA & BGM Systems

الكود: EC-SMR

High-Quality Audio Playback Supports up to 320 kbps HD MP3 audio files and streaming media for background music playback with real-time or scheduled loop tasks across single or multiple zones. Flexible Zone & Group Management Unlimited grouping capability allows users to freely create and manage zones based on different sites, functions, or devices with a simple and intuitive system setup. Advanced Task Scheduling Supports multiple task types, including Real-time tasks，Time-based rule tasks and Triggered tasks, enables loop playback within defined time periods for automated operation. Third-Party System Integration* Supports SIP or IMS relay creation for connection with external SIP servers or telecom carriers, enabling inbound/outbound calling and centralized call control. * Working with VOlP-100 system manager Stable Server-Grade Platform Powered by an Intel® Core™ processor and enterprise-class components to ensure stable, long-term operation in mission-critical environments. Compact 1U Rackmount Design Space-saving 1U chassis suitable for standard 19-inch racks, ideal for equipment rooms and data centers. Reliable Network Connectivity Gigabit LAN interface ensures stable and secure data transmission for IP audio systems.

استفسار واتساب طلب عرض سعر تحميل الكتالوج

المواصفات الفنية

Model
EC-SMR
Power Supply
AC 110–240 V or DC 12 V, 5 A
Processor
Intel® Core™ i5-3317U (Dual-Core / 4 Threads, 1.7 GHz)
Graphics
Integrated Graphics
Memory
DDR3 DIMM, 4 GB installed
Storage
1× SATA 3.0 + 1× mSATA; 128 GB mSATA installed
Rear I/O
2× USB 3.0, 2× USB 2.0, 1× Gigabit Ethernet, 1× HDMI, 1× VGA
Front I/O
2× USB 2.0, Power Switch
Operating Temperature
0℃ to 50℃
Operating Humidity
-20% to 80% RH (Non-condensing)
Mounting
Rackmount or Desktop
Dimensions (W×D×H)
440 × 250 × 45 mm
Finish
Matt Black
Net Weight
3.24kg

الاستخدامات

High-Quality Audio Playback Supports up to 320 kbps HD MP3 audio files and streaming media for background music playback with real-time or scheduled loop tasks across single or multiple zones.
Flexible Zone & Group Management Unlimited grouping capability allows users to freely create and manage zones based on different sites, functions, or devices with a simple and intuitive system setup.
Advanced Task Scheduling Supports multiple task types, including Real-time tasks，Time-based rule tasks and Triggered tasks, enables loop playback within defined time periods for automated operation.
Third-Party System Integration* Supports SIP or IMS relay creation for connection with external SIP servers or telecom carriers, enabling inbound/outbound calling and centralized call control. * Working with VOlP-100 system manager
Stable Server-Grade Platform Powered by an Intel® Core™ processor and enterprise-class components to ensure stable, long-term operation in mission-critical environments.
Compact 1U Rackmount Design Space-saving 1U chassis suitable for standard 19-inch racks, ideal for equipment rooms and data centers.
Reliable Network Connectivity Gigabit LAN interface ensures stable and secure data transmission for IP audio systems.
